Custom Tubing adapter STL file ⌀ 250–90 mm (Length: 225 mm) 📦#3684

STL Download STL
Create a new model:
from scratch search for a model
Straight sleeve ⌀250 mm to ⌀90 mm in STL 3D format. Final length of this sleeve is 225 mm. The larger-diameter tube has a thickness of 20 mm and a sleeve length of 5 mm. The smaller-diameter tube has a thickness of 3 mm and a length of 170 mm. The ends have a fillet on the outside to facilitate the connection of the two tubes.
Generation date: 2025-11-25
3D Model Tubing adapter STL file ⌀ 250–90 mm (Length: 225 mm)

3D model download

Free
  • inline-tube-adapter-lenA5mm-di_model3684-nb0_dd{id}.stl : 13.3 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 5 mm (≃3/16 in)
#2 side A outer diameter 250 mm (≃9.84 in)
#3 side A thickness 20 mm (≃0.79 in)
#4 side B length 170 mm (≃6 11/16 in)
#5 side B outer diameter 90 mm (≃3.54 in)
#6 side B thickness 3 mm (≃1/8 in)
#7 transition length 50 mm (≃1.97 in)
#8 axis offset 00 mm (0 in)
#9 ends fillet fillet on the outside
Metadata Value
inner diameter (side A) 210 mm (≃8.27 in)
inner diameter (side B) 84 mm (≃3 5/16 in)
total length 225 mm (≃8.86 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
