Custom Washer / Flat Gasket STL 3D file ⌀ID: 15 mm ⌀OD: 20 mm thickness: 2.5 mm + chamfer 📦#3635
Generation date: 2025-11-25
3D model download
Free- washer-flat-gasket-ring-inD15m_model3635-nb0_dd{id}.stl : 135.4 Ko
STL
Mesh quality :
0.0005
0.05
No compliance warranty
License: CC0 - Creative commons
(no copyright - public domain)
Safe download
Values for this model
This model was generated by the Washer, Flat gasket, Ring template, with the following values:
| Parameter | Value | |
|---|---|---|
| #1 | inner diameter | 15 mm (≃0.59 in) |
| #2 | outer diameter | 20 mm (≃0.79 in) |
| #3 | thickness | 2.5 mm (≃0.10 in) |
| #4 | finish | chamfer |
| #5 | finish position | inner |
| #6 | sides | one side |
| #7 | finish value | 0.4 mm (≃0.02 in) |
Parameter overview
Labels are used in the naming of the downloaded 3D files.
| Parameter | Label |
|---|---|
| #1 inner diameter | inD |
| #2 outer diameter | ouD |
| #3 thickness | thi |
| #4 finish | edgF |
| #5 finish position | edgP |
| #6 sides | sidC |
| #7 finish value | finV |
