Custom Tube adapter STL file ⌀ 24–10 mm (Length: 90 mm) 📦#3388

STL Download STL
Create a new model:
from scratch search for a model
Tubing adapter ⌀24 mm to ⌀10 mm in STL 3D format. Length of this fitting is 90 mm. The larger-diameter tube has a thickness of 2.8 mm and a length of 30 mm. The smaller-diameter tube has a thickness of 3 mm and a length of 30 mm as well. The ends feature an external fillet to facilitate the connection of the two tubes.
Generation date: 2025-11-18
3D Model Tube adapter STL file ⌀ 24–10 mm (Length: 90 mm)

3D model download

Free
  • inline-tube-adapter-lenA30mm-d_model3388-nb0_dd{id}.stl : 4.1 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 30 mm (≃1 3/16 in)
#2 side A outer diameter 24 mm (≃15/16 in)
#3 side A thickness 2.8 mm (≃1/8 in)
#4 side B length 30 mm (≃1 3/16 in)
#5 side B outer diameter 10 mm (≃0.39 in)
#6 side B thickness 3 mm (≃1/8 in)
#7 transition length 30 mm (≃1 3/16 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet fillet on the outside
Metadata Value
inner diameter (side A) 18.4 mm (≃0.72 in)
inner diameter (side B) 4 mm (≃0.16 in)
total length 90 mm (≃3.54 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
