Diameter adapter ⌀50 mm to ⌀46 mm in STL format. Final length of this coupler is 90 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 30 mm, the smaller one of 35 mm. The ends are not rounded.
Generation date: 2025-11-10
3D Model Tube adapter STL 3D file ⌀ 50–46 mm (Length: 90 mm)

3D model download

Free
  • inline-tube-adapter-lenA30mm-d_model3179-nb0_dd{id}.stl : 393.8 Ko
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 30 mm (≃1 3/16 in)
#2 side A outer diameter 50 mm (≃1.97 in)
#3 side A thickness 2 mm (≃0.08 in)
#4 side B length 35 mm (≃1 3/8 in)
#5 side B outer diameter 46 mm (≃1 13/16 in)
#6 side B thickness 2 mm (≃0.08 in)
#7 transition length 25 mm (≃0.98 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 46 mm (≃1 13/16 in)
inner diameter (side B) 42 mm (≃1.65 in)
total length 90 mm (≃3.54 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
