Custom Tube adapter STL 3D file ⌀ 150–110 mm (Length: 195 mm) 📦#2697

STL Download STL 2
Create a new model expert
from scratch search for a model
Straight sleeve ⌀150 mm to ⌀110 mm in STL 3D format. Length of this adapter is 195 mm. The thickness of the tubes is identical: 4 mm. The larger-diameter tube has a sleeve length of 35 mm, the smaller one of 60 mm. The ends have a fillet on the outside.
Generation date: 2025-10-23
3D Model Tube adapter STL 3D file ⌀ 150–110 mm (Length: 195 mm)

3D model download

Free
  • inline-tube-adapter-lenA35mm-d_model2697-nb0_dd{id}.stl : 3.8 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 35 mm (≃1 3/8 in)
#2 side A outer diameter 150 mm (≃5.91 in)
#3 side A thickness 4 mm (≃0.16 in)
#4 side B length 60 mm (≃2 3/8 in)
#5 side B outer diameter 110 mm (≃4.33 in)
#6 side B thickness 4 mm (≃0.16 in)
#7 transition length 100 mm (≃3 15/16 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet fillet on the outside
Metadata Value
inner diameter (side A) 142 mm (≃5.59 in)
inner diameter (side B) 102 mm (≃4.02 in)
total length 195 mm (≃7 11/16 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
