Round-to-Rectangular Tube Adapter ⌀56 mm to 80×80 mm, thickness 3 mm 📦#1845
Generation date: 2025-09-17
3D model download
Free- round-to-rectangular-adapter-d_model1845-nb0_dd{id}.stl : 3.3 Mo
STL
Mesh quality :
0.0005
0.05
License: ITE IPU v1.0 - Iteration3d
(Internal and private use, non-commercial – no distribution – no derivatives)
Values for this model
This model was generated by the Round to rectangular adapter template, with the following values:
| Parameter | Value | |
|---|---|---|
| #1 | cylinder outer diameter | 56 mm |
| #2 | cylinder inlet length | 15 mm |
| #3 | rectangle internal length | 80 mm |
| #4 | rectangle internal height | 80 mm |
| #5 | rectangle inlet length | 15 mm |
| #6 | offset Z | 0 mm |
| #7 | offset Y | 0 mm |
| #8 | total length | 50 mm |
| #9 | thickness | 3 mm |
| #10 | chamfer | chamfers on the outside of the cylindrical tube and on the inside of the rectangular tube |
Representation of the parameters
- If the chamfer option on the ends is enabled, the chamfer length is equal to half the thickness.
- The stop at the bottom of the rectangular section has a width equal to half the thickness.
Labels are used in the naming of the downloaded 3D files.
| Parameter | Label |
|---|---|
| #1 cylinder outer diameter | diaC |
| #2 cylinder inlet length | lentC |
| #3 rectangle internal length | lenIR |
| #4 rectangle internal height | heiIR |
| #5 rectangle inlet length | lentR |
| #6 offset Z | ofsZ |
| #7 offset Y | ofsY |
| #8 total length | lenT |
| #9 thickness | thi |
| #10 chamfer | cha |
