Tube adapter STL 3D file ⌀ 50–39 mm (Length: 390 mm) 📦#1461

STL Download STL
Create a new model:
from scratch search for a model
Tube connector ⌀50 mm to ⌀39 mm in STL 3D format. Total length of this fitting is 390 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 60 mm, the smaller one of 300 mm. The two axes of the tubes are off-center by 5 mm. The ends have a fillet on the outside.
Generation date: 2025-08-28
3D Model Tube adapter STL 3D file ⌀ 50–39 mm (Length: 390 mm)

3D model download

Free
  • inline-tube-adapter-lenA60mm-d_model1461-nb0_dd{id}.stl : 3.9 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 60 mm
#2 side A outer diameter 50 mm
#3 side A thickness 2 mm
#4 side B length 300 mm
#5 side B outer diameter 39 mm
#6 side B thickness 2 mm
#7 transition length 30 mm
#8 axis offset 5 mm
#9 ends fillet fillet on the outside
illustration of the parameters
Representation of the parameters

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
