Pipe elbow 180° ⌀OD: 20 mm ⌀ID: 16 mm thickness: 2 mm 📦#1379

Model of a pipe elbow with a 180° angle in STL format. This elbow has an external diameter of 20 mm and an internal diameter of 16 mm. This results in a tube thickness of 2 mm.

Generation date: 2025-08-20

3D Model Pipe elbow 180° ⌀OD: 20 mm ⌀ID: 16 mm thickness: 2 mm

3D model download

Free

Download format: zip : 1.6 Mo (1 file(s))

pipe-elbow-ouD20mm-inD16mm-deg_model1379-nb0_dd{id}.stl : 1.6 Mo

STL Mesh quality : 0.001 0.1

License: CC BY-NC-ND - Creative commons

(attribution - non commercial use - no derivatives)

Photos of the model once printed

Pipe elbow 180° ⌀OD: 20 mm ⌀ID: 16 mm thickness: 2 mm

Values for this model

This model was generated by the Pipe elbow template, with the following values:

	Template parameter	Value	Unit	Label
#1	outer diameter	20	mm	ouD
#2	inner diameter	16	mm	inD
#3	angle	180	°	deg
#4	end fillets	0	0,1	fil

Representation of the parameters
