Custom Tube elbow STL 3D file 180° ⌀OD: 40 mm ⌀ID: 37 mm thickness: 1.5 mm 📦#11769

STL Download STL 1
Create a new model easy
from scratch search for a model
3D file of an elbow with a 180° angle in STL format. This pipe elbow features an outer diameter of 40 mm and an inner diameter of 37 mm. This results in a tube thickness of 1.5 mm.
Generation date: 2026-09-17
3D Model Tube elbow STL 3D file 180° ⌀OD: 40 mm ⌀ID: 37 mm thickness: 1.5 mm

3D model download

Free
  • pipe-elbow-ouD40mm-inD37mm-deg_model11769-nb0_dd{id}.stl : 1.6 Mo
STL Mesh quality : Linear deflection 0.001 Angular deflection 0.1
No compliance warranty No compliance warranty
(Internal and private use, non-commercial – no distribution – no derivatives)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Pipe elbow template, with the following values:
Parameter Value
#1 outer diameter 40 mm (≃1 9/16 in)
#2 inner diameter 37 mm (≃1.46 in)
#3 angle 180 °
#4 end fillets no
Metadata Value
Tube wall thickness 1.5 mm (≃1/16 in)
illustration of the parameters
Parameter overview

  • The length of the straight sections is equal to the outer diameter of the tube.
  • The arc radius is equal to the outer diameter of the tube.
  • If the end fillet option is enabled, the fillet radius applied to the inside and outside of the tube is equal to half the wall thickness minus 0.1 mm, never exceeding 3 mm.

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 outer diameter ouD
#2 inner diameter inD
#3 angle deg
#4 end fillets fil
