Honeycomb grid / fan guard 3D Files - Length or center-to-center 50 to 100 mm

Find the listing of 3D models of honeycomb grid / fan guard with length or center-to-center 50 to 100 mm, sorted in ascending order.

You can also run a model search here

8 Model(s)

Honeycomb grille STL file, center-to-center: 50x50mm, mesh: 10mm - Ø8mm (📦 #2909)

1 object(s) - format STL

3D honeycomb square grid model in STL format. Mounting holes are placed at the four corners (center-to-center 50x50 mm), each with a diameter of Ø8 mm. The overall dimensions reach 66x66 mm, with very open 10 mm cell size for maximum airflow. This grid functions as both a mechanical guard and a ventilation panel.

Parameter	Value	Unit
length or center-to-center	50	mm
width or center-to-center	50	mm
mesh size	10	mm
dual color	no
holes	yes
hole diameter	8	mm

Protective grid STL 3D file, center-to-center: 70x70mm, mesh: 10mm - Ø4mm (📦 #2824)

1 object(s) - format STL

Square protective honeycomb grid model in STL format. Mounting holes are placed at the four corners (center-to-center 70x70 mm), each with a diameter of Ø4 mm. The overall dimensions reach 78x78 mm, with extra wide 10 mm cell size for peak ventilation. This type of grid provides mechanical protection and ventilation.

Parameter	Value	Unit
length or center-to-center	70	mm
width or center-to-center	70	mm
mesh size	10	mm
dual color	no
holes	yes
hole diameter	4	mm

Honeycomb grid STL 3D file, center-to-center: 70x70mm, mesh: 10mm - Ø4mm (📦 #3015)

2 object(s) - format STL

3D square grid model as a STL file. Mounting holes are placed at the four corners (center-to-center 70x70 mm), each with a diameter of Ø4 mm. The overall dimensions reach 78x78 mm, with extra wide 10 mm cell size for maximum airflow. A secondary color frame emphasizes the border. This grid serves as both a protective guard and a ventilation panel.

Parameter	Value	Unit
length or center-to-center	70	mm
width or center-to-center	70	mm
mesh size	10	mm
dual color	yes
holes	yes
hole diameter	4	mm

Honeycomb grid STL file, center-to-center: 75x75mm, mesh: 10mm - Ø8mm (📦 #2907)

1 object(s) - format STL

Download this 3D square grid file in STL format. Mounting holes are placed at the four corners (center-to-center 75x75 mm), each with a diameter of Ø8 mm. The overall dimensions reach 91x91 mm, with very open 10 mm cell size for peak ventilation. This grid serves as both a protective guard and a ventilation panel.

Parameter	Value	Unit
length or center-to-center	75	mm
width or center-to-center	75	mm
mesh size	10	mm
dual color	no
holes	yes
hole diameter	8	mm

Honeycomb grid STL file, center-to-center: 80x80mm, mesh: 5mm - Ø5mm (📦 #2722)

1 object(s) - format STL

Download this 3D honeycomb square grid model in STL format. Mounting holes are placed at the four corners (center-to-center 80x80 mm), each with a diameter of Ø5 mm. The overall dimensions reach 90x90 mm, with regular 5 mm cell size for versatile use. This grid provides both mechanical protection and airflow.

Parameter	Value	Unit
length or center-to-center	80	mm
width or center-to-center	80	mm
mesh size	5	mm
dual color	no
holes	yes
hole diameter	5	mm

Protective grid STL 3D file, center-to-center: 80x66mm, mesh: 7mm - Ø5mm (📦 #2726)

1 object(s) - format STL

Download this 3D honeycomb protective rectangular grid model in STL format. Mounting holes are placed at the four corners (center-to-center 80x66 mm), each with a diameter of Ø5 mm. The overall dimensions reach 90x76 mm, with large 7 mm cell size to enhance ventilation. This type of grid provides mechanical protection and ventilation.

Parameter	Value	Unit
length or center-to-center	80	mm
width or center-to-center	66	mm
mesh size	7	mm
dual color	no
holes	yes
hole diameter	5	mm

Protective grid STL file, 80x80mm, mesh: 10mm (📦 #3040)

1 object(s) - format STL

Honeycomb protective square grid file in STL format. The overall size is 80x80 mm, with extra wide 10 mm cell size for peak ventilation. This type of grid serves both protection and ventilation roles.

Parameter	Value	Unit
length or center-to-center	80	mm
width or center-to-center	80	mm
mesh size	10	mm
dual color	no
holes	no

Honeycomb grid STL 3D file, 90x90mm, mesh: 3mm (📦 #2972)

1 object(s) - format STL

3D square honeycomb grid model as a STL file. The overall size is 90x90 mm, with very fine 3 mm cell size for maximum protection. This type of grid provides mechanical protection and ventilation.

Parameter	Value	Unit
length or center-to-center	90	mm
width or center-to-center	90	mm
mesh size	3	mm
dual color	no
holes	no

Can't find the right model? Create it with your parameters
