Inline tube adapter 3D Files - Side A outer diameter 5 to 100 mm | page 8

Inline tube reducer ⌀80 mm to ⌀30 mm in STL 3D format. Length of this reducer is 63 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 5 mm, the smaller one of 20 mm. The ends are raw.

Inline sleeve ⌀80 mm to ⌀32 mm in STL format. Total length of this fitting is 110 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 30 mm, the smaller one of 60 mm. The two axes of the tubes are offset by 10 mm. The ends feature an internal fillet to make tube connection easier.

Inline sleeve ⌀80 mm to ⌀46 mm in STL 3D format. Length of this fitting is 160 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a length of 80 mm, the smaller one of 60 mm. The ends have no fillet.

Inline tube reducer ⌀80 mm to ⌀22 mm in STL 3D format. Length of this sleeve is 49 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a sleeve length of 10 mm, the smaller one of 9 mm. The ends have no fillet.

Inline fitting ⌀80 mm to ⌀50 mm in STL format. Length of this coupler is 700 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a length of 300 mm, the smaller one of 300 mm as well. The ends are raw.

Inline sleeve ⌀81 mm to ⌀55 mm in STL 3D format. Final length of this connector is 80 mm. The thickness of the tubes is identical: 2.5 mm. The larger-diameter tube has a sleeve length of 25 mm, the smaller one of 25 mm as well. The ends are rounded on the outside.

Inline tube coupler ⌀81 mm to ⌀61 mm in STL 3D format. Final length of this coupler is 115 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a sleeve length of 15 mm, the smaller one of 15 mm as well. The ends have no fillet.

Inline fitting ⌀82 mm to ⌀61 mm in STL format. Total length of this connector is 100 mm. The larger-diameter tube has a thickness of 2 mm and a length of 20 mm. The smaller-diameter tube has a thickness of 3 mm and a length of 20 mm as well. The ends are not rounded.

Straight sleeve ⌀82 mm to ⌀63 mm in STL format. Length of this junction is 75 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 25 mm, the smaller one of 25 mm as well. The ends have a fillet on the inside.

Tubing adapter ⌀83 mm to ⌀63 mm in STL 3D format. Length of this adapter is 120 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 15 mm, the smaller one of 15 mm as well. The ends have no fillet.

Tube coupler ⌀85 mm to ⌀29 mm in STL format. Total length of this reducer is 140 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 20 mm, the smaller one of 20 mm as well. The axes of the tubes are off-center by 27 mm. The ends are not rounded.

Inline tube junction ⌀85 mm to ⌀29 mm in STL format. Length of this sleeve is 180 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a sleeve length of 40 mm, the smaller one of 40 mm as well. The axes of the tubes are off-center by 27 mm. The ends have no fillet.

Tube coupler ⌀85 mm to ⌀60 mm in STL format. Final length of this connector is 45 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a length of 20 mm, the smaller one of 20 mm as well. The ends have no fillet.

Straight tube fitting ⌀85 mm to ⌀70 mm in STL 3D format. Length of this sleeve is 80 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a length of 30 mm, the smaller one of 30 mm as well. The two axes of the tubes are off-center by 7.4 mm. The ends are raw.

Inline sleeve ⌀85 mm to ⌀65 mm in STL 3D format. Total length of this reducer is 111 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 45 mm, the smaller one of 45 mm as well. The ends have no fillet.

Tube connector ⌀85 mm to ⌀54 mm in STL format. Total length of this junction is 120 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 60 mm, the smaller one of 55 mm. The axes of the tubes are offset by 5 mm. The ends have a fillet.

Inline tube coupler ⌀86 mm to ⌀81 mm in STL format. Total length of this reducer is 111 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 46 mm, the smaller one of 45 mm. The ends are rounded on the outside to make tube connection easier.

Tube fitting ⌀86 mm to ⌀66 mm in STL format. Length of this reducer is 70 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a sleeve length of 20 mm, the smaller one of 20 mm as well. The ends have no fillet.

Straight tubing adapter ⌀86 mm to ⌀75 mm in STL format. Final length of this junction is 160 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 70 mm, the smaller one of 60 mm. The ends have no fillet.

Tube coupler ⌀88 mm to ⌀25 mm in STL format. Total length of this adapter is 63 mm. The thickness of the tubes is identical: 4 mm. The larger-diameter tube has a length of 25 mm, the smaller one of 25 mm as well. The ends have no fillet.

Tube connector ⌀90 mm to ⌀68 mm in STL 3D format. Final length of this junction is 90 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 15 mm, the smaller one of 30 mm. The two axes of the tubes are offset by 10 mm. The ends are not rounded.

Inline tube coupler ⌀90 mm to ⌀50 mm in STL 3D format. Total length of this connector is 130 mm. The thickness of the tubes is identical: 2.5 mm. The larger-diameter tube has a length of 50 mm, the smaller one of 40 mm. The two axes of the tubes are offset by 1 mm. The ends feature an external fillet to make tube connection easier.

Tubing adapter ⌀90 mm to ⌀85 mm in STL 3D format. Final length of this junction is 39 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 18 mm, the smaller one of 16 mm. The ends are not rounded.

Straight tube adapter ⌀90 mm to ⌀80 mm in STL 3D format. Final length of this coupler is 48 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a sleeve length of 18 mm, the smaller one of 25 mm. The ends have no fillet.

Inline tube reducer ⌀90 mm to ⌀82 mm in STL 3D format. Length of this sleeve is 48 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 18 mm, the smaller one of 25 mm. The ends have no fillet.

Inline tubing adapter ⌀90 mm to ⌀46 mm in STL format. Total length of this junction is 50 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 10 mm, the smaller one of 20 mm. The ends have no fillet.

Inline sleeve ⌀92 mm to ⌀71 mm in STL 3D format. Total length of this adapter is 90 mm. The larger-diameter tube has a thickness of 3 mm and a sleeve length of 10 mm. The smaller-diameter tube has a thickness of 2 mm and a length of 50 mm. The axes of the tubes are offset by 9.1 mm. The ends are raw.

Straight tube fitting ⌀94 mm to ⌀90 mm in STL 3D format. Length of this adapter is 80 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a sleeve length of 30 mm, the smaller one of 30 mm as well. The ends feature an external fillet to make tube connection easier.

Straight sleeve ⌀94 mm to ⌀60 mm in STL 3D format. Total length of this sleeve is 80 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 20 mm, the smaller one of 20 mm as well. The two axes of the tubes are offset by 15 mm. The ends are raw.

Inline sleeve ⌀94 mm to ⌀80 mm in STL 3D format. Total length of this coupler is 80 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 20 mm, the smaller one of 50 mm. The axes of the tubes are off-center by 5.9 mm. The ends are rounded on the outside.
