Tube adapter ⌀ 7–5.5 mm (Length: 15 mm) (📦 #1104)

1 object(s) - format STL (3.8/5) 5 vote(s)

3D model Tube adapter ⌀ 7–5.5 mm (Length: 15 mm)

Tube adapter ⌀7 mm to ⌀5.5 mm in STL format. Final length of this junction is 15 mm. The thickness of the tubes is identical: 2 mm. The ends are raw.

Parameter	Value	Unit
side A length	5	mm
side A outer diameter	7	mm
side A thickness	2	mm
side B length	5	mm
side B outer diameter	5.5	mm
side B thickness	2	mm
transition length	5	mm
axis offset	0.6	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 16–12 mm (Length: 35 mm) (📦 #1097)

1 object(s) - format STL

3D model Tube adapter ⌀ 16–12 mm (Length: 35 mm)

Inline fitting ⌀16 mm to ⌀12 mm in STL format. Final length of this fitting is 35 mm. The thickness of the tubes is identical: 2 mm. The ends are rounded to ease the connection.

Parameter	Value	Unit
side A length	15	mm
side A outer diameter	16	mm
side A thickness	2	mm
side B length	15	mm
side B outer diameter	12	mm
side B thickness	2	mm
transition length	5	mm
axis offset	0	mm
ends fillet	3	0,1,2,3

Tube adapter ⌀ 16–10 mm (Length: 15 mm) (📦 #1466)

1 object(s) - format STL

3D model Tube adapter ⌀ 16–10 mm (Length: 15 mm)

Tube connector ⌀16 mm to ⌀10 mm in STL format. Final length of this junction is 15 mm. The thickness of the tubes is identical: 2 mm. The ends are raw.

Parameter	Value	Unit
side A length	5	mm
side A outer diameter	16	mm
side A thickness	2	mm
side B length	5	mm
side B outer diameter	10	mm
side B thickness	2	mm
transition length	5	mm
axis offset	0	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 20–5 mm (Length: 65 mm) (📦 #1261)

1 object(s) - format STL (5.0/5) 1 vote(s)

3D model Tube adapter ⌀ 20–5 mm (Length: 65 mm)

Inline tube junction ⌀20 mm to ⌀5 mm in STL format. Total length of this coupler is 65 mm. The thickness of the tubes is identical: 2 mm. The ends feature an external fillet to ease the connection.

Parameter	Value	Unit
side A length	30	mm
side A outer diameter	20	mm
side A thickness	2	mm
side B length	30	mm
side B outer diameter	5	mm
side B thickness	2	mm
transition length	5	mm
axis offset	0	mm
ends fillet	1	0,1,2,3

Tube adapter ⌀ 25–20 mm (Length: 45 mm) (📦 #1101)

1 object(s) - format STL

3D model Tube adapter ⌀ 25–20 mm (Length: 45 mm)

Tube reducer ⌀25 mm to ⌀20 mm in STL format. Length of this reducer is 45 mm. The thickness of the tubes is identical: 3 mm. The ends are rounded on the inside to make tube connection easier.

Parameter	Value	Unit
side A length	15	mm
side A outer diameter	25	mm
side A thickness	3	mm
side B length	15	mm
side B outer diameter	20	mm
side B thickness	3	mm
transition length	15	mm
axis offset	0	mm
ends fillet	2	0,1,2,3

Tube adapter ⌀ 30–26 mm (Length: 50 mm) (📦 #1109)

1 object(s) - format STL (3.0/5) 1 vote(s)

3D model Tube adapter ⌀ 30–26 mm (Length: 50 mm)

Inline tube adapter ⌀30 mm to ⌀26 mm in STL format. Final length of this reducer is 50 mm. The thickness of the tubes is identical: 2 mm. The ends have no fillet.

Parameter	Value	Unit
side A length	15	mm
side A outer diameter	30	mm
side A thickness	2	mm
side B length	30	mm
side B outer diameter	26	mm
side B thickness	2	mm
transition length	5	mm
axis offset	0	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 32–25 mm (Length: 25 mm) (📦 #1103)

1 object(s) - format STL (5.0/5) 1 vote(s)

3D model Tube adapter ⌀ 32–25 mm (Length: 25 mm)

Inline tube reducer ⌀32 mm to ⌀25 mm in STL format. Final length of this reducer is 25 mm. The thickness of the tubes is identical: 2 mm. The ends are not rounded.

Parameter	Value	Unit
side A length	10	mm
side A outer diameter	32	mm
side A thickness	2	mm
side B length	10	mm
side B outer diameter	25	mm
side B thickness	2	mm
transition length	5	mm
axis offset	0	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 33–19 mm (Length: 56 mm) (📦 #1338)

1 object(s) - format STL

3D model Tube adapter ⌀ 33–19 mm (Length: 56 mm)

Tube junction ⌀33 mm to ⌀19 mm in STL format. Total length of this fitting is 56 mm. The thickness of the tubes is identical: 4 mm. The two axes of the tubes are offset. The ends have no fillet.

Parameter	Value	Unit
side A length	19	mm
side A outer diameter	33	mm
side A thickness	4	mm
side B length	10	mm
side B outer diameter	19	mm
side B thickness	4	mm
transition length	27	mm
axis offset	6.1	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 38–10 mm (Length: 90 mm) (📦 #1269)

1 object(s) - format STL

3D model Tube adapter ⌀ 38–10 mm (Length: 90 mm)

Tube connector ⌀38 mm to ⌀10 mm in STL format. Final length of this fitting is 90 mm. The thickness of the larger diameter tube is 2.5 mm, and the smaller one is 2 mm. The ends are rounded on the outside.

Parameter	Value	Unit
side A length	30	mm
side A outer diameter	38	mm
side A thickness	2.5	mm
side B length	30	mm
side B outer diameter	10	mm
side B thickness	2	mm
transition length	30	mm
axis offset	0	mm
ends fillet	1	0,1,2,3

Tube adapter ⌀ 44–16 mm (Length: 90 mm) (📦 #1270)

1 object(s) - format STL

3D model Tube adapter ⌀ 44–16 mm (Length: 90 mm)

Tube connector ⌀44 mm to ⌀16 mm in STL format. Length of this connector is 90 mm. The thickness of the larger diameter tube is 2.5 mm, and the smaller one is 2 mm. The ends have no fillet.

Parameter	Value	Unit
side A length	30	mm
side A outer diameter	44	mm
side A thickness	2.5	mm
side B length	30	mm
side B outer diameter	16	mm
side B thickness	2	mm
transition length	30	mm
axis offset	0	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 45–10 mm (Length: 90 mm) (📦 #1260)

1 object(s) - format STL (4.0/5) 1 vote(s)

3D model Tube adapter ⌀ 45–10 mm (Length: 90 mm)

Inline sleeve ⌀45 mm to ⌀10 mm in STL format. Final length of this junction is 90 mm. The thickness of the larger diameter tube is 2.5 mm, and the smaller one is 2 mm. The ends have no fillet.

Parameter	Value	Unit
side A length	30	mm
side A outer diameter	45	mm
side A thickness	2.5	mm
side B length	30	mm
side B outer diameter	10	mm
side B thickness	2	mm
transition length	30	mm
axis offset	0	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 45–9 mm (Length: 90 mm) (📦 #1271)

1 object(s) - format STL

3D model Tube adapter ⌀ 45–9 mm (Length: 90 mm)

Tube reducer ⌀45 mm to ⌀9 mm in STL format. Final length of this coupler is 90 mm. The thickness of the larger diameter tube is 2.5 mm, and the smaller one is 2 mm. The ends are raw.

Parameter	Value	Unit
side A length	30	mm
side A outer diameter	45	mm
side A thickness	2.5	mm
side B length	30	mm
side B outer diameter	9	mm
side B thickness	2	mm
transition length	30	mm
axis offset	0	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 45–15 mm (Length: 90 mm) (📦 #1272)

1 object(s) - format STL

3D model Tube adapter ⌀ 45–15 mm (Length: 90 mm)

Inline sleeve ⌀45 mm to ⌀15 mm in STL format. Length of this junction is 90 mm. The thickness of the larger diameter tube is 2.5 mm, and the smaller one is 2 mm. The ends are raw.

Parameter	Value	Unit
side A length	30	mm
side A outer diameter	45	mm
side A thickness	2.5	mm
side B length	30	mm
side B outer diameter	15	mm
side B thickness	2	mm
transition length	30	mm
axis offset	0	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 45–10 mm (Length: 97 mm) (📦 #1443)

1 object(s) - format STL

3D model Tube adapter ⌀ 45–10 mm (Length: 97 mm)

Straight tube coupler ⌀45 mm to ⌀10 mm in STL format. Length of this junction is 97 mm. The thickness of the larger diameter tube is 2.5 mm, and the smaller one is 2 mm. The ends are not rounded.

Parameter	Value	Unit
side A length	30	mm
side A outer diameter	45	mm
side A thickness	2.5	mm
side B length	37	mm
side B outer diameter	10	mm
side B thickness	2	mm
transition length	30	mm
axis offset	0	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 50–40 mm (Length: 45 mm ) (📦 #1094)

1 object(s) - format STL (5.0/5) 2 vote(s)

3D model Tube adapter ⌀ 50–40 mm (Length: 45 mm )

Inline tube junction ⌀50 to ⌀40 mm in STL format. Length of this connector is 45 mm. The thickness of the larger diameter tube is 4 mm, and the smaller one is 3 mm. The ends have a fillet on the outside to make tube connection easier.

Parameter	Value	Unit
side A length	20	mm
side A outer diameter	50	mm
side A thickness	4	mm
side B length	20	mm
side B outer diameter	40	mm
side B thickness	3	mm
transition length	5	mm
axis offset	0	mm
ends fillet	1	0,1,2,3

Tube adapter ⌀ 50–40 mm (Length: 50 mm) (📦 #1124)

1 object(s) - format STL

3D model Tube adapter ⌀ 50–40 mm (Length: 50 mm)

Straight tube coupler ⌀50 mm to ⌀40 mm in STL format. Length of this reducer is 50 mm. The thickness of the tubes is identical: 2 mm. The ends have a fillet.

Parameter	Value	Unit
side A length	20	mm
side A outer diameter	50	mm
side A thickness	2	mm
side B length	20	mm
side B outer diameter	40	mm
side B thickness	2	mm
transition length	10	mm
axis offset	0	mm
ends fillet	3	0,1,2,3

Tube adapter ⌀ 50–40 mm (Length: 100 mm) (📦 #1125)

1 object(s) - format STL (4.0/5) 1 vote(s)

3D model Tube adapter ⌀ 50–40 mm (Length: 100 mm)

Diameter adapter ⌀50 mm to ⌀40 mm in STL format. Final length of this fitting is 100 mm. The thickness of the tubes is identical: 2 mm. The ends are rounded to facilitate the connection of the two tubes.

Parameter	Value	Unit
side A length	40	mm
side A outer diameter	50	mm
side A thickness	2	mm
side B length	40	mm
side B outer diameter	40	mm
side B thickness	2	mm
transition length	20	mm
axis offset	0	mm
ends fillet	3	0,1,2,3

Tube adapter ⌀ 50–30 mm (Length: 95 mm) (📦 #1314)

1 object(s) - format STL

3D model Tube adapter ⌀ 50–30 mm (Length: 95 mm)

Inline tube junction ⌀50 mm to ⌀30 mm in STL format. Total length of this reducer is 95 mm. The thickness of the larger diameter tube is 5 mm, and the smaller one is 3 mm. The ends have a fillet to ease the connection.

Parameter	Value	Unit
side A length	30	mm
side A outer diameter	50	mm
side A thickness	5	mm
side B length	50	mm
side B outer diameter	30	mm
side B thickness	3	mm
transition length	15	mm
axis offset	0	mm
ends fillet	3	0,1,2,3

Tube adapter ⌀ 50–39 mm (Length: 390 mm) (📦 #1461)

1 object(s) - format STL

3D model Tube adapter ⌀ 50–39 mm (Length: 390 mm)

Inline tube reducer ⌀50 mm to ⌀39 mm in STL format. Final length of this coupler is 390 mm. The thickness of the tubes is identical: 2 mm. The two axes of the tubes are offset. The ends have a fillet on the outside.

Parameter	Value	Unit
side A length	60	mm
side A outer diameter	50	mm
side A thickness	2	mm
side B length	300	mm
side B outer diameter	39	mm
side B thickness	2	mm
transition length	30	mm
axis offset	5	mm
ends fillet	1	0,1,2,3

Tube adapter ⌀ 51–35 mm (Length: 75 mm) (📦 #1289)

1 object(s) - format STL

3D model Tube adapter ⌀ 51–35 mm (Length: 75 mm)

Diameter adapter ⌀51 mm to ⌀35 mm in STL format. Length of this coupler is 75 mm. The thickness of the larger diameter tube is 6 mm, and the smaller one is 3 mm. The ends are rounded to make tube connection easier.

Parameter	Value	Unit
side A length	30	mm
side A outer diameter	51	mm
side A thickness	6	mm
side B length	30	mm
side B outer diameter	35	mm
side B thickness	3	mm
transition length	15	mm
axis offset	0	mm
ends fillet	3	0,1,2,3

Tube adapter ⌀ 51–35 mm (Length: 80 mm) (📦 #1290)

1 object(s) - format STL

3D model Tube adapter ⌀ 51–35 mm (Length: 80 mm)

Tube reducer ⌀51 mm to ⌀35 mm in STL format. Final length of this adapter is 80 mm. The thickness of the tubes is identical: 3 mm. The ends have a fillet to ease the connection.

Parameter	Value	Unit
side A length	30	mm
side A outer diameter	51	mm
side A thickness	3	mm
side B length	30	mm
side B outer diameter	35	mm
side B thickness	3	mm
transition length	20	mm
axis offset	0	mm
ends fillet	3	0,1,2,3

Tube adapter ⌀ 60–30 mm (Length: 140 mm) (📦 #1100)

1 object(s) - format STL (5.0/5) 2 vote(s)

3D model Tube adapter ⌀ 60–30 mm (Length: 140 mm)

Inline tube reducer ⌀60 mm to ⌀30 mm in STL format. Total length of this sleeve is 140 mm. The thickness of the larger diameter tube is 4 mm, and the smaller one is 3 mm. The two axes of the tubes are offset. The ends are raw.

Parameter	Value	Unit
side A length	20	mm
side A outer diameter	60	mm
side A thickness	4	mm
side B length	20	mm
side B outer diameter	30	mm
side B thickness	3	mm
transition length	100	mm
axis offset	13.9	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 60–40 mm (Length: 85 mm) (📦 #1123)

1 object(s) - format STL

3D model Tube adapter ⌀ 60–40 mm (Length: 85 mm)

Straight sleeve ⌀60 mm to ⌀40 mm in STL format. Total length of this reducer is 85 mm. The thickness of the tubes is identical: 3 mm. The axes of the tubes are offset. The ends feature an external fillet to make tube connection easier.

Parameter	Value	Unit
side A length	40	mm
side A outer diameter	60	mm
side A thickness	3	mm
side B length	40	mm
side B outer diameter	40	mm
side B thickness	3	mm
transition length	5	mm
axis offset	1	mm
ends fillet	1	0,1,2,3

Tube adapter ⌀ 60–45 mm (Length: 100 mm) (📦 #1228)

1 object(s) - format STL

3D model Tube adapter ⌀ 60–45 mm (Length: 100 mm)

Straight tube coupler ⌀60 mm to ⌀45 mm in STL format. Total length of this connector is 100 mm. The thickness of the tubes is identical: 4 mm. The ends have no fillet.

Parameter	Value	Unit
side A length	50	mm
side A outer diameter	60	mm
side A thickness	4	mm
side B length	30	mm
side B outer diameter	45	mm
side B thickness	4	mm
transition length	20	mm
axis offset	0	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 60–45 mm (Length: 75 mm) (📦 #1234)

1 object(s) - format STL

3D model Tube adapter ⌀ 60–45 mm (Length: 75 mm)

Tube coupler ⌀60 mm to ⌀45 mm in STL format. Final length of this adapter is 75 mm. The thickness of the tubes is identical: 3 mm. The ends are not rounded.

Parameter	Value	Unit
side A length	30	mm
side A outer diameter	60	mm
side A thickness	3	mm
side B length	30	mm
side B outer diameter	45	mm
side B thickness	3	mm
transition length	15	mm
axis offset	0	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 61–12 mm (Length: 90 mm) (📦 #1325)

1 object(s) - format STL

3D model Tube adapter ⌀ 61–12 mm (Length: 90 mm)

Tube adapter ⌀61 mm to ⌀12 mm in STL format. Length of this adapter is 90 mm. The thickness of the tubes is identical: 2 mm. The two axes of the tubes are offset. The ends are raw.

Parameter	Value	Unit
side A length	20	mm
side A outer diameter	61	mm
side A thickness	2	mm
side B length	20	mm
side B outer diameter	12	mm
side B thickness	2	mm
transition length	50	mm
axis offset	20	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 61–15 mm (Length: 80 mm) (📦 #1326)

1 object(s) - format STL

3D model Tube adapter ⌀ 61–15 mm (Length: 80 mm)

Tube fitting ⌀61 mm to ⌀15 mm in STL format. Total length of this sleeve is 80 mm. The thickness of the tubes is identical: 2 mm. The ends are not rounded.

Parameter	Value	Unit
side A length	20	mm
side A outer diameter	61	mm
side A thickness	2	mm
side B length	20	mm
side B outer diameter	15	mm
side B thickness	2	mm
transition length	40	mm
axis offset	0	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 61–12 mm (Length: 95 mm) (📦 #1339)

1 object(s) - format STL (5.0/5) 1 vote(s)

3D model Tube adapter ⌀ 61–12 mm (Length: 95 mm)

Inline tube reducer ⌀61 mm to ⌀12 mm in STL format. Final length of this fitting is 95 mm. The thickness of the tubes is identical: 2 mm. The axes of the tubes are off-center. The ends are not rounded.

Parameter	Value	Unit
side A length	25	mm
side A outer diameter	61	mm
side A thickness	2	mm
side B length	20	mm
side B outer diameter	12	mm
side B thickness	2	mm
transition length	50	mm
axis offset	20	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 64–49 mm (Length: 63 mm) (📦 #1229)

1 object(s) - format STL

3D model Tube adapter ⌀ 64–49 mm (Length: 63 mm)

Tube reducer ⌀64 mm to ⌀49 mm in STL format. Final length of this fitting is 63 mm. The thickness of the tubes is identical: 4 mm. The ends are not rounded.

Parameter	Value	Unit
side A length	25	mm
side A outer diameter	64	mm
side A thickness	4	mm
side B length	25	mm
side B outer diameter	49	mm
side B thickness	4	mm
transition length	13	mm
axis offset	0	mm
ends fillet	0	0,1,2,3

Tube adapter ⌀ 64–49 mm (Length: 65 mm) (📦 #1230)

1 object(s) - format STL

3D model Tube adapter ⌀ 64–49 mm (Length: 65 mm)

Inline tube adapter ⌀64 mm to ⌀49 mm in STL format. Final length of this coupler is 65 mm. The thickness of the larger diameter tube is 4 mm, and the smaller one is 3 mm. The ends are raw.

Parameter	Value	Unit
side A length	25	mm
side A outer diameter	64	mm
side A thickness	4	mm
side B length	25	mm
side B outer diameter	49	mm
side B thickness	3	mm
transition length	15	mm
axis offset	0	mm
ends fillet	0	0,1,2,3

Can't find the right model? Create it with your parameters
