Custom Honeycomb grid STL file, 250x250mm, mesh: 10mm 📦#4396

STL Download STL 11
Create a new model advanced
from scratch search for a model
Square grid model as a STL file. The overall size is 250x250 mm, with very large 10 mm cell size for maximum airflow. This grid serves as both a protective guard and a ventilation panel.
Generation date: 2025-12-06
3D Model Honeycomb grid STL file, 250x250mm, mesh: 10mm

3D model download

Free
  • honeycomb-grid-loc250mm-woc250_model4396-nb0_dd{id}.stl : 872.9 Ko
STL Mesh quality : Linear deflection 0.001 Angular deflection 0.1
No compliance warranty No compliance warranty
(Internal and private use, non-commercial – no distribution – no derivatives)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Honeycomb grid / fan guard template, with the following values:
Parameter Value
#1 length or center-to-center 250 mm (≃9.84 in)
#2 width or center-to-center 250 mm (≃9.84 in)
#3 mesh size 10 mm (≃0.39 in)
#4 dual color no
#5 holes no
#6 hole diameter -
Metadata Value
total length 250 mm (≃9.84 in)
total width 250 mm (≃9.84 in)
thickness 2 mm (≃0.08 in)
illustration of the parameters
Parameter overview

The thickness of the walls forming the honeycomb structure is 1.2 mm.

  • When no holes are present, the width of the outer band is 1.5 mm.
  • When holes are present, the width of the outer band is equal to half the hole diameter.

When holes are present, the boss (reinforcing collar around the holes) has a diameter equal to twice the hole diameter.

When holes are present, the distance between the center of a hole and the outer edge of the frame is equal to the hole diameter.

The grid thickness is fixed at 2 mm.

The outer rim features a 1 mm rounded edge (fillet) on all four corners.

When the dual color parameter is enabled, the external band has a width equal to 30% of the hole diameter (0.9 mm when no holes are present).

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 length or center-to-center loc
#2 width or center-to-center woc
#3 mesh size mes
#4 dual color duaC
#5 holes hol
#6 hole diameter hod
