Custom Pipe clip holder Ø89 mm STL file · Pan head screw Ø7 mm 📦#3494
Generation date: 2025-11-21
3D model download
Free- pipe-clip-holder-dia89mm-hod7m_model3494-nb0_dd{id}.stl : 134.2 Ko
STL
Mesh quality :
0.001
0.1
No compliance warranty
License: ITE IPU v1.0 - Iteration3d
(Internal and private use, non-commercial – no distribution – no derivatives)
Safe download
Values for this model
This model was generated by the Pipe clip holder template, with the following values:
| Parameter | Value | |
|---|---|---|
| #1 | tube diameter | 89 mm (≃3 1/2 in) |
| #2 | hole diameter | 7 mm (≃0.28 in) |
| #3 | countersunk screw | no |
| Metadata | Value |
|---|---|
| width | 18.2 mm (≃0.72 in) |
Parameter overview
Labels are used in the naming of the downloaded 3D files.
| Parameter | Label |
|---|---|
| #1 tube diameter | dia |
| #2 hole diameter | hod |
| #3 countersunk screw | scrT |
