Round-to-Rectangular Tube Adapter STL file ⌀57 mm to 29×19 mm, thickness 3 mm 📦#2991

STL Download STL
Create a new model:
from scratch search for a model
3D model in STL format of a round-to-rectangular adapter with an outer diameter of ⌀57 mm and a rectangular section with internal dimensions 29×19 mm. The wall thickness is 3 mm and the total length is 96 mm.
Generation date: 2025-11-02
3D Model Round-to-Rectangular Tube Adapter STL file ⌀57 mm to 29×19 mm, thickness 3 mm

3D model download

Free
  • round-to-rectangular-adapter-d_model2991-nb0_dd{id}.stl : 2 Mo
STL Mesh quality : Linear deflection 0.0005 Angular deflection 0.05
No compliance warranty No compliance warranty
(Internal and private use, non-commercial – no distribution – no derivatives)
Safe download

Values for this model

This model was generated by the Round to rectangular adapter template, with the following values:
Parameter Value
#1 cylinder outer diameter 57 mm
#2 cylinder inlet length 25 mm
#3 rectangle internal length 29 mm
#4 rectangle internal height 19 mm
#5 rectangle inlet length 50 mm
#6 offset Z 0 mm
#7 offset Y 0 mm
#8 total length 96 mm
#9 thickness 3 mm
#10 chamfer no chamfer
Metadata Value
Cylinder internal diameter 51 mm
illustration of the parameters
Representation of the parameters

  • If the chamfer option on the ends is enabled, the chamfer length is equal to half the thickness.
  • The stop at the bottom of the rectangular section has a width equal to half the thickness.

Labels are used in the naming of the downloaded 3D files.
