Multi-compartment box STL file: 14 compartments of 100×30×30 mm 📦#2204

STL Download STL
Create a new model:
from scratch search for a model
This STL 3D model features 14 sections measuring 100×30×30mm each. The total dimensions are 716×66×32mm. Fillets of 5mm applied to all compartments make it easier to grasp items stored in slots.
Generation date: 2025-10-05
3D Model Multi-compartment box STL file: 14 compartments of 100×30×30 mm

3D model download

Free
  • multi-compartment-storage-box-_model2204-nb0_dd{id}.stl : 1.3 Mo
STL Mesh quality : Linear deflection 0.5 Angular deflection 0.3
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Values for this model

This model was generated by the Multi-compartment storage box template, with the following values:
Parameter Value
#1 number of rows 2
#2 number of columns 7
#3 compartment length 100 mm
#4 compartment width 30 mm
#5 compartment height 30 mm
#6 wall thickness 2 mm
#7 compartment fillet (radius) 5 mm
Metadata Value
total length 716 mm
total width 66 mm
total height 32 mm
number of slots 14
illustration of the parameters
Representation of the parameters

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 number of rows nbR
#2 number of columns nbC
#3 compartment length coL
#4 compartment width coW
#5 compartment height coH
#6 wall thickness waT
#7 compartment fillet (radius) coF
