Pipe elbow 10° ⌀OD: 40 mm ⌀ID: 34.8 mm thickness: 2.6 mm 📦#1740

STL Download STL
Create a new model:
from scratch search for a model
3D file of a pipe elbow with a 10° angle in STL format. This elbow features an external diameter of 40 mm and an internal diameter of 34.8 mm. This results in a tube thickness of 2.6 mm.
Generation date: 2025-09-11
3D Model Pipe elbow 10° ⌀OD: 40 mm ⌀ID: 34.8 mm thickness: 2.6 mm

3D model download

Free
  • pipe-elbow-ouD40mm-inD34.8mm-d_model1740-nb0_dd{id}.stl : 172.3 Ko
STL Mesh quality : Linear deflection 0.001 Angular deflection 0.1
(Internal and private use, non-commercial – no distribution – no derivatives)

Values for this model

This model was generated by the Pipe elbow template, with the following values:
Parameter Value
#1 outer diameter 40 mm
#2 inner diameter 34.8 mm
#3 angle 10 °
#4 end fillets no
illustration of the parameters
Representation of the parameters

  • The length of the straight sections is equal to the outer diameter of the tube.
  • The arc radius is equal to the outer diameter of the tube.
  • If the end fillet option is enabled, the fillet radius applied to the inside and outside of the tube is equal to half the wall thickness minus 0.1 mm, never exceeding 3 mm.

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 outer diameter ouD
#2 inner diameter inD
#3 angle deg
#4 end fillets fil
