Custom Round air vent STL 3D file ∅ 300 mm, slat angle: 60° with central reinforcement 📦#1285

STL Download STL 1
Create a new model easy
from scratch search for a model
3D file of a round grille for air circulation in STL format. Its insertion diameter measures 300 mm. The slats have a steep angle of 60° and a high thickness of 2.4 mm. A centered vertical reinforcement strengthens the slats. This vent cover has a collar of 10 mm. The total diameter of this model is 320 mm.
Generation date: 2025-07-28
3D Model Round air vent STL 3D file ∅ 300 mm, slat angle: 60° with central reinforcement

3D model download

Free
  • round-air-vent-dia300mm-slD60d_model1285-nb0_dd{id}.stl : 6.2 Mo
STL Mesh quality : not defined
No compliance warranty No compliance warranty
(attribution - non commercial use - no derivatives)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Round air vent grill template, with the following values:
Parameter Value
#1 male diameter 300 mm (≃11 13/16 in)
#2 slat angle 60 °
#3 slat thickness 2.4 mm (≃0.09 in)
#4 flange width 10 mm (≃0.39 in)
#5 central reinforcement yes
Metadata Value
Total diameter (including flange) 320 mm (≃12.60 in)
Total thickness 25 mm (≃0.98 in)
illustration of the parameters
Parameter overview

  • The total thickness of the vent is 25 mm.
  • Whatever the parameters, the slats never overlap. This ensures an optimal airflow. At the same time, the slats form an almost opaque screen along the axis.
  • The slats are actually shaped as parallelograms rather than rectangles. This ensures better printability.
  • The slats and the central reinforcement (if present) feature a 0.40 mm fillet on all edges. This improves airflow and prevents potential whistling.
  • The collar, if present, is 3 mm thick and has a 2 mm fillet for aesthetic purposes.
  • The male insertion area is 3 mm thick and has a 1 mm fillet on both edges to facilitate insertion into the intended slot.
  • The central reinforcement, if present, is 2 mm thick and spans the entire projected width of the slats.

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 male diameter dia
#2 slat angle slD
#3 slat thickness slT
#4 flange width flW
#5 central reinforcement renf
