Custom Enclosure with screw-mounted lid STL file: 200×130×60 mm (with ventilation on the lid and under the enclosure) 📦#1247

STL Download STL 5
Create a new model expert
from scratch search for a model
Enclosure with screwed lid in 3D STL format. The dimensions are 200 mm long by 130 mm wide and 60 mm high. The cover only is 10 mm high. Wall thickness is 3 mm. This enclosure features cooling area on the lid and under the base.
Generation date: 2025-07-22
thumb object 0
object #0
thumb object 1
object #1
3D Model Enclosure with screw-mounted lid STL file: 200×130×60 mm (with ventilation on the lid and under the enclosure)

3D model download

Free
  • object #0 enclosure-with-screw-mounted-l_model1247-nb0_dd{id}.stl : 640.1 Ko
  • object #1 enclosure-with-screw-mounted-l_model1247-nb1_dd{id}.stl : 563.6 Ko
STL Mesh quality : not defined
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Enclosure with screw-mounted lid template, with the following values:
Parameter Value
#1 length 200 mm (≃7 7/8 in)
#2 width 130 mm (≃5 1/8 in)
#3 total height 60 mm (≃2 3/8 in)
#4 lid height 10 mm (≃0.39 in)
#5 wall thickness 3 mm (≃1/8 in)
#6 screw margin 0 mm (0 in)
#7 fit clearance 0.1 mm (<0.01 in)
#8 cooling level 3
#9 cooling zone(s) cutouts on both
Metadata Value
Internal length excluding screw mounting posts 194 mm (≃7 5/8 in)
Internal width excluding screw mounting posts 124 mm (≃4 7/8 in)
Internal height 52 mm (≃2 1/16 in)
illustration of the parameters
Parameter overview

  • The thickness of the upper lid shell is always 5 mm.

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 length len
#2 width wid
#3 total height Thei
#4 lid height Lhei
#5 wall thickness waT
#6 screw margin Tmrg
#7 fit clearance Imrg
#8 cooling level cooL
#9 cooling zone(s) cooZ
