Custom Round-to-Rectangular Tube Adapter STL 3D file ⌀69.5 mm to 142×24 mm, thickness 2 mm + offset 📦#11378

STL Download STL 1
Create a new model expert
from scratch search for a model
Download this file in STL format of a round-to-rectangular adapter with an external diameter of ⌀69.5 mm and a rectangular section with internal dimensions 142×24 mm. The wall thickness is 2 mm and the overall length is 180 mm. The adapter has an offset of 22.5 mm along the Z axis. A chamfer is applied on the inside of the rectangular end.
Generation date: 2026-09-01
3D Model Round-to-Rectangular Tube Adapter STL 3D file ⌀69.5 mm to 142×24 mm, thickness 2 mm + offset

3D model download

Free
  • round-to-rectangular-adapter-d_model11378-nb0_dd{id}.stl : 1.4 Mo
STL Mesh quality : Linear deflection 0.0005 Angular deflection 0.05
No compliance warranty No compliance warranty
(Internal and private use, non-commercial – no distribution – no derivatives)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Round to rectangular adapter template, with the following values:
Parameter Value
#1 cylinder outer diameter 69.5 mm (≃2 3/4 in)
#2 cylinder inlet length 50 mm (≃1.97 in)
#3 rectangle internal length 142 mm (≃5.59 in)
#4 rectangle internal height 24 mm (≃15/16 in)
#5 rectangle inlet length 40 mm (≃1 9/16 in)
#6 offset Z 22.5 mm (≃7/8 in)
#7 offset Y 0 mm (0 in)
#8 total length 180 mm (≃7.09 in)
#9 thickness 2 mm (≃0.08 in)
#10 chamfer chamfer on the inside
of the rectangular tube
Metadata Value
Cylinder internal diameter 65.5 mm (≃2.58 in)
illustration of the parameters
Parameter overview

  • If the chamfer option on the ends is enabled, the chamfer length is equal to half the thickness.
  • The stop at the bottom of the rectangular section has a width equal to half the thickness.

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 cylinder outer diameter diaC
#2 cylinder inlet length lentC
#3 rectangle internal length lenIR
#4 rectangle internal height heiIR
#5 rectangle inlet length lentR
#6 offset Z ofsZ
#7 offset Y ofsY
#8 total length lenT
#9 thickness thi
#10 chamfer cha
