Custom Enclosure with screw-mounted lid STL 3D file: 300×150×100 mm (with ventilation on the lid) 📦#3979
Generation date: 2025-11-28
3D model download
Free- object #0 enclosure-with-screw-mounted-l_model3979-nb0_dd{id}.stl : 276.4 Ko
- object #1 enclosure-with-screw-mounted-l_model3979-nb1_dd{id}.stl : 1.2 Mo
STL
Mesh quality :
0.1
0.1
No compliance warranty
License: CC BY - Creative commons
(attribution - commercial use allowed)
Safe download
Values for this model
This model was generated by the Enclosure with screw-mounted lid template, with the following values:
| Parameter | Value | |
|---|---|---|
| #1 | length | 300 mm (≃11 13/16 in) |
| #2 | width | 150 mm (≃5.91 in) |
| #3 | total height | 100 mm (≃3 15/16 in) |
| #4 | lid height | 20 mm (≃0.79 in) |
| #5 | wall thickness | 3 mm (≃1/8 in) |
| #6 | screw margin | 0.1 mm (<0.01 in) |
| #7 | fit clearance | 0.1 mm (<0.01 in) |
| #8 | cooling level | 5 |
| #9 | cooling zone(s) | cutouts on the lid |
| Metadata | Value |
|---|---|
| Internal length excluding screw mounting posts | 294 mm (≃11 9/16 in) |
| Internal width excluding screw mounting posts | 144 mm (≃5.67 in) |
| Internal height | 92 mm (≃3 5/8 in) |
Parameter overview
- The thickness of the upper lid shell is always 5 mm.
Labels are used in the naming of the downloaded 3D files.
| Parameter | Label |
|---|---|
| #1 length | len |
| #2 width | wid |
| #3 total height | Thei |
| #4 lid height | Lhei |
| #5 wall thickness | waT |
| #6 screw margin | Tmrg |
| #7 fit clearance | Imrg |
| #8 cooling level | cooL |
| #9 cooling zone(s) | cooZ |
