Custom Tubing elbow STL file 115° ⌀OD: 47 mm ⌀ID: 44 mm thickness: 1.5 mm 📦#2928

STL Download STL 2
Create a new model easy
from scratch search for a model
3D model of a tubing elbow with a 115° angle in STL format. This pipe elbow has an outer diameter of 47 mm and an inner diameter of 44 mm. The tube thickness is therefore 1.5 mm.
Generation date: 2025-10-31
3D Model Tubing elbow STL file 115° ⌀OD: 47 mm ⌀ID: 44 mm thickness: 1.5 mm

3D model download

Free
  • pipe-elbow-ouD47mm-inD44mm-deg_model2928-nb0_dd{id}.stl : 1.1 Mo
STL Mesh quality : Linear deflection 0.001 Angular deflection 0.1
No compliance warranty No compliance warranty
(Internal and private use, non-commercial – no distribution – no derivatives)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Pipe elbow template, with the following values:
Parameter Value
#1 outer diameter 47 mm (≃1.85 in)
#2 inner diameter 44 mm (≃1.73 in)
#3 angle 115 °
#4 end fillets no
Metadata Value
Tube wall thickness 1.5 mm (≃1/16 in)
illustration of the parameters
Parameter overview

  • The length of the straight sections is equal to the outer diameter of the tube.
  • The arc radius is equal to the outer diameter of the tube.
  • If the end fillet option is enabled, the fillet radius applied to the inside and outside of the tube is equal to half the wall thickness minus 0.1 mm, never exceeding 3 mm.

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 outer diameter ouD
#2 inner diameter inD
#3 angle deg
#4 end fillets fil
