Pipe elbow STL file 90° ⌀OD: 64 mm ⌀ID: 58 mm thickness: 3 mm 📦#2431

STL Download STL
Create a new model:
from scratch search for a model
File of a pipe elbow with a 90° angle in STL format. This pipe elbow features an external diameter of 64 mm and an internal diameter of 58 mm. This results in a tube thickness of 3 mm. The ends feature fillets to make it easier to assemble.
Generation date: 2025-10-14
3D Model Pipe elbow STL file 90° ⌀OD: 64 mm ⌀ID: 58 mm thickness: 3 mm

3D model download

Free
  • pipe-elbow-ouD64mm-inD58mm-deg_model2431-nb0_dd{id}.stl : 2.4 Mo
STL Mesh quality : Linear deflection 0.001 Angular deflection 0.1
No compliance warranty No compliance warranty
(Internal and private use, non-commercial – no distribution – no derivatives)
Safe download

Values for this model

This model was generated by the Pipe elbow template, with the following values:
Parameter Value
#1 outer diameter 64 mm
#2 inner diameter 58 mm
#3 angle 90 °
#4 end fillets yes
illustration of the parameters
Representation of the parameters

  • The length of the straight sections is equal to the outer diameter of the tube.
  • The arc radius is equal to the outer diameter of the tube.
  • If the end fillet option is enabled, the fillet radius applied to the inside and outside of the tube is equal to half the wall thickness minus 0.1 mm, never exceeding 3 mm.

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 outer diameter ouD
#2 inner diameter inD
#3 angle deg
#4 end fillets fil
